ATmega4HVD/8HVD

17.8

Register Description

17.8.1

ADCSRA – ADC Control and Status Register A

• Bit 7 – ADEN: ADC Enable

Writing this bit to one enables the ADC. By writing it to zero, the ADC is turned off. Turning the
ADC off while a conversion is in progress, will terminate this conversion.

• Bit 6 – ADSC: ADC Start Conversion

Write this bit to one to start each conversion. The first conversion after ADSC has been written
after the ADC has been enabled, or if ADSC is written at the same time as the ADC is
enabled, will take 27 ADC clock cycles. The conversion time will then be 13 ADC cycles if
ADTEMP is set to zero, or 27 ADC cycles if ADTEMP is set to one. This first conversion per-
forms initialization of the ADC.

ADSC will read as one as long as a conversion is in progress. When the conversion is com-
plete, it returns to zero. Writing zero to this bit has no effect.

• Bit 5 – RES: Reserved bits

These bits are reserved, and will always read as zero.

• Bit 4 – ADIF: ADC Interrupt Flag

This bit is set when an ADC conversion completes and the data registers are updated. The
ADC Conversion Complete Interrupt is executed if the ADIE bit and the I-bit in SREG are set.
ADIF is cleared by hardware when executing the corresponding interrupt handling vector.
Alternatively, ADIF is cleared by writing a logical one to the flag. Beware that if doing a Read-
Modify-Write on ADCSRA, a pending interrupt can be disabled. This also applies if the SBI
and CBI instructions are used.

• Bit 3 – ADIE: ADC Interrupt Enable

When this bit is written to one and the I-bit in SREG is set, the ADC Conversion Complete
Interrupt is activated.

• Bit 2 – RES: Reserved bit

This bit isreserved, and will always read as zero.

• Bit 1:0 – ADMUX1:0: ADC Channel Selection Bits

These bits selects the analog input that should be connected to the ADC according to

Table

17-3

. If these bits are changed during a conversion, the change will not be effective until the

conversion is complete.

Bit

7

6

5

4

3

2

1

0

ADEN

ADSC

-

ADIF

ADIE

-

ADMUX1

ADMUX0

ADCSRA

Read/Write

R/W

R/W

R

R/W

R/W

R

R/W

R/W

Initial Value

0

0

0

0

0

0

0

0
