ATmega4HVD/8HVD
Interrupts must be disabled when changing prescaler setting to make sure the write procedure
is not interrupted.
8.11 ADC Clock Prescaler
The ADC clock will be automatically prescaled relative to the System Clock Prescaler settings,
see
”System Clock Prescaler” on page 25 . Depending on the Clock Prescale Select bits,
CLKPS1..0, the ADC clock, clk
ADC
, will be prescaled by 24, 12 or 6 as shown in Table 8-3 on
page 26 .
Note: 1. When changing Prescaler value, the ADC Prescaler will automatically change frequency of
the ADC. The result of the ongoing conversion will be invalid.
Table 8-3. ADC Clock Prescaling (1)
CLKPS1 CLKPS0 ADC Division Factor
0 0 Reserved
0 1 24
1 0 12
1 1 6
