14
8052B–AVR–09/08
ATmega4HVD/8HVD
7. AVR Memories
7.1 Overview
This section describes the different memories in the ATmega4HVD/8HVD. The AVR architec-
ture has two main memory spaces, the Data Memory and the Program Memory space. In
addition, the ATmega4HVD/8HVD features an EEPROM Memory for data storage. All three
memory spaces are linear and regular.
7.2 In-System Reprogrammable Flash Program Memory
The ATmega4HVD/8HVD contains 4/8K bytes On-chip In-System Reprogrammable Flash
memory for program storage. Since all AVR instructions are 16 or 32 bits wide, the Flash is
organized as 2K/4K x 16.
The Flash memory has an endurance of at least 10,000 write/erase cycles. The
ATmega4HVD/8HVD Program Counter (PC) is 11/12 bits wide, thus addressing the 2K/4K
program memory locations.
”Memory Programming” on page 129 contains a detailed descrip-
tion on Flash data serial downloading.
Constant tables can be allocated within the entire program memory address space (see the
LPM – Load Program Memory instruction description).
Timing diagrams for instruction fetch and execution are presented in ”Instruction Execution
Timing” on page 11 .
Figure 7-1. Program Memory Map
Program Memory, organized as 2K/4K x 16 bits
0x0000
0x7FF/0xFFF
