142
8052B–AVR–09/08
ATmega4HVD/8HVD
26. Electrical Characteristics
Absolute Maximum Ratings*
26.1 DC Characteristics
Operating Temperature.................................... -20°C to +85°C *NOTICE: Stresses beyond those listed under “Absolute
Maximum Ratings” may cause permanent dam-
age to the device. This is a stress rating only and
functional operation of the device at these or
other conditions beyond those indicated in the
operational sections of this specification is not
implied. Exposure to absolute maximum rating
conditions for extended periods may affect
device reliability.
Storage Temperature ..................................... -65°C to +150°C
Voltage on PB0 - PB2, VCC, and NI
with respect to Ground ............................. -0.5V to VCC
+0.5V
Voltage on PV1 and BATT
with respect to Ground .....................................-0.5V to + 8.0V
Voltage on PC0 and PC1
with respect to Ground .....................................-0.5V to + 5.0V
Voltage on VFET with respect to Ground ..........-0.5V to + 12V
Maximum Voltage in RESET...............................-0.5V to + 13V
Voltage on OC, OD and BATT
with respect to Ground ......................................-0.5V to + 12V
Maximum Operating Voltage on VFET ............................. 6.0V
Table 26-1. Electrical Characteristics (1) , T
A
= -20°C to 85°C, VFET = 2.4 to 4.2V (unless otherwise noted)
Parameter Condition Min Typ Max Unit
Supply
Current
Active
1 MHz,
All PRR bits set
420
μ
A idle 150
ADC Noise Reduction 290
Active
1 MHz,
Only ADC Enabled
1.2 mA
Idle 300
μ
A
ADC Noise Reduction 4 MHz, Only ADC Enabled 360
Power-save
DUVR mode Disabled,
Battery protection Enabled,
OC/OD Enabled
35 TBD
μ
A DUVR mode Disabled
Battery protection Disabled,
OC/OD Disabled
23
Power-off VFET < 4.0V 0.1 1
