ATmega4HVD/8HVD
(0x7D) Reserved – – – – – – – –
(0x7C) Reserved – – – – – – – –
(0x7B) Reserved – – – – – – – –
(0x7A) ADCSRA ADEN ADSC – ADIF ADIE – ADMUX1 ADMUX0
(0x79) ADCH – – – – – – ADC9 ADC8
(0x78) ADCL ADC[7:0]
(0x77) Reserved – – – – – – – –
(0x76) Reserved – – – – – – – –
(0x75) Reserved – – – – – – – –
(0x74) Reserved – – – – – – – –
(0x73) Reserved – – – – – – – –
(0x72) Reserved – – – – – – – –
(0x71) Reserved – – – – – – – –
(0x70) Reserved – – – – – – – –
(0x6F) TIMSK1 – – – – ICIE1 OCIE1B OCIE1A TOIE1
(0x6E) TIMSK0 – – – – ICIE0 OCIE0B OCIE0A TOIE0
(0x6D) Reserved – – – – – – – –
(0x6C) Reserved – – – – – – – –
(0x6B) Reserved – – – – – – – –
(0x6A) Reserved – – – – – – – –
(0x69) EICRA – – – – ISC11 ISC10 ISC01 ISC00
(0x68) Reserved – – – – – – – –
(0x67) Reserved – – – – – – – –
(0x66) FOSCCAL Fast Oscillator Calibration Register
(0x65) Reserved – – – – – – – –
(0x64) PRR0 – – PRVRM – PRSPI PRTIM1 PRTIM0 PRADC
(0x63) Reserved – – – – – – – –
(0x62) Reserved – – – – – – – –
(0x61) CLKPR CLKPCE – – – – – CLKPS1 CLKPS0
(0x60) WDTCSR WDIF WDIE WDP3 WDCE WDE WDP2 WDP1 WDP0
0x3F (0x5F) SREG I T H S V N Z C
0x3E (0x5E) SPH SP15 SP14 SP13 SP12 SP11 SP10 SP9 SP8
0x3D (0x5D) SPL SP7 SP6 SP5 SP4 SP3 SP2 SP1 SP0
0x3C (0x5C) Reserved – – – – – – – –
0x3B (0x5B) Reserved – – – – – – – –
0x3A (0x5A) Reserved – – – – – – – –
0x39 (0x59) Reserved – – – – – – – –
0x38 (0x58) Reserved – – – – – – – –
0x37 (0x57) SPMCSR – – SIGRD CTPB RFLB PGWRT PGERS SPMEN
0x36 (0x56) Reserved – – – – – – – –
0x35 (0x55) MCUCR – – CKOE PUD – – – –
0x34 (0x54) MCUSR – – – OCDRF WDRF – EXTRF PORF
0x33 (0x53) SMCR – – – – SM2 SM1 SM0 SE
0x32 (0x52) Reserved – – – – – – – –
0x31 (0x51) DWDR debugWIRE Data Register
0x30 (0x50) Reserved – – – – – – – –
0x2F (0x4F) Reserved – – – – – – – –
0x2E (0x4E) Reserved – – – – – – – –
0x2D (0x4D) Reserved – – – – – – – –
0x2C (0x4C) Reserved – – – – – – – –
0x2B (0x4B) GPIOR2 General Purpose I/O Register 2
0x2A (0x4A) GPIOR1 General Purpose I/O Register 1
0x29 (0x49) OCR0B Timer/Counter0 - Output Compare Register A
0x28 (0x48) OCR0A Timer/Counter0 - Output Compare Register B
0x27 (0x47) TCNT0H Timer/Counter0 - Counter Register High Byte
0x26 (0x46) TCNT0L Timer/Counter0 - Counter Register Low Byte
0x25 (0x45) TCCR0B – – – – – CS02 CS01 CS00
0x24 (0x44) TCCR0A TCW0 ICEN0 ICNC0 ICES0 ICS0 – – WGM00
0x23 (0x43) GTCCR TSM – – – – – – PSR
0x22 (0x42) Reserved – – – – – – – –
0x21 (0x41) EEARL EEPROM Address Register
0x20 (0x40) EEDR EEPROM Data Register
0x1F (0x3F) EECR – – EEPM1 EEPM0 EERIE EEMPE EEPE EERE
0x1E (0x3E) GPIOR0 General Purpose I/O Register 0
0x1D (0x3D) EIMSK – – – – – – INT1 INT0
0x1C (0x3C) EIFR – – – – – – INTF1 INTF0
Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Page
