ATmega4HVD/8HVD
16.10 Register Description
16.10.1 TCCRnA – Timer/Counter n Control Register A
• Bit 7– TCWn: Timer/Counter Width
When this bit is written to one 16-bit mode is selected. The Timer/Counter width is set to 16-
bits and the Output Compare Registers OCRnA and OCRnB are combined to form one 16-bit
Output Compare Register. Because the 16-bit registers TCNTnH/L and OCRnB/A are
accessed by the AVR CPU via the 8-bit data bus, special procedures must be followed. These
procedures are described in section
”Accessing Registers in 16-bit Mode” on page 82 .
• Bit 6– ICENn: Input Capture Mode Enable
The Input Capture Mode is enabled when this bit is written to one.
• Bit 5 – ICNCn: Input Capture Noise Canceler
Setting this bit activates the Input Capture Noise Canceler. When the noise canceler is acti-
vated, the input from the Input Capture Source is filtered. The filter function requires four
successive equal valued samples of the Input Capture Source for changing its output. The
Input Capture is therefore delayed by four System Clock cycles when the noise canceler is
enabled.
• Bit 4 – ICESn: Input Capture Edge Select
This bit selects which edge on the Input Capture Source that is used to trigger a capture event.
When the ICESn bit is written to zero, a falling (negative) edge is used as trigger, and when
the ICESn bit is written to one, a rising (positive) edge will trigger the capture. When a capture
is triggered according to the ICESn setting, the counter value is copied into the Input Capture
Register. The event will also set the Input Capture Flag (ICFn), and this can be used to cause
an Input Capture Interrupt, if this interrupt is enabled.
• Bit 3 - ICSn: Input Capture Select
When written logic one, this bit enables the input capture function in Timer/Counter to be trig-
gered by the alternative Input Capture Source. To make the comparator trigger the
Timer/Counter Input Capture interrupt, the ICIEn bit in the Timer Interrupt Mask Register
(TIMSK) must be set. See
Table 16-3 on page 80 and Table 16-4 on page 80 .
• Bits 2:0 – Res: Reserved Bits
These bits are reserved bits in the ATmega4HVD/8HVD and will always read as zero.
• Bit 0 – WGMn0: Waveform Generation Mode
This bit controls the counting sequence of the counter, the source for maximum (TOP) counter
value, see
Figure 16-6 on page 81 . Modes of operation supported by the Timer/Counter unit
are: Normal mode (counter) and Clear Timer on Compare Match (CTC) mode (see
”Timer/Counter Timing Diagrams” on page 81 ).
Bit 7 6 5 4 3 2 1 0
TCWn ICENn ICNCn ICESn ICSn – – WGMn0 TCCRnA
Read/Write R/W R/W R/W R/W R/W R R R/W
Initial Value 0 0 0 0 0 0 0 0
