DS26503 T1/E1/J1 BITS Element
91 of 123
Figure 13-5. Protected Interface Using Internal Receive Termination
TTIP
TRING
RTIP
RRING
DVDD
TVDD
RVDD
V
DD
V
DD
DVSS
TVSS
RVSS
DS26503
68 mF
2:1
1:1
D1 D2
D3
D4
C1
F1
F2
F3
F4
S1
0.1 mF
0.1 mF
0.1 mF
0.01 mF
X1
X2
TRANSMIT
LINE
RECEIVE
LINE
0.1 mF
10 mF
10 mF
+
+
+
0.1 mF
S2
60 60
V
DD
D5 D6
D7
D8
0.1 mF
NOTES:
1) All resistor values are ±1%.
2) X1 and X2 are very low DCR transformers
3) C1 = 10
mF ceramic.
4) S1 and S2 are 6V transient suppressers.
5) D1 to D8 are Schottky diodes.
6) The fuses, F1–F4, are optional to prevent AC power-line crosses from compromising the
transformers.
7) The 68 mF is used to keep the local power-plane potential within tolerance during a surge.
