DS26503 T1/E1/J1 BITS Element
66 of 123
Register Name:
RRA
Register Description: Receive Remote Alarm
Register Address: 5Ah
Bit
# 7 6 5 4 3 2 1 0
Name RRAF1 RRAF3 RRAF5 RRAF7 RRAF9 RRAF11 RRAF13 RRAF15
Default
0 0 0 0 0 0 0 0
HW
Mode
X X X X X X X X
Bit 0/Remote Alarm Bit of Frame 15(RRAF15).
Bit 1/Remote Alarm Bit of Frame 13(RRAF13).
Bit 2/Remote Alarm Bit of Frame 11(RRAF11).
Bit 3/Remote Alarm Bit of Frame 9(RRAF9).
Bit 4/Remote Alarm Bit of Frame 7(RRAF7).
Bit 5/Remote Alarm Bit of Frame 5(RRAF5).
Bit 6/Remote Alarm Bit of Frame 3(RRAF3).
Bit 7/Remote Alarm Bit of Frame 1(RRAF1).
Register Name:
RSa4
Register Description: Receive Sa4 Bits
Register Address: 5Bh
Bit
# 7 6 5 4 3 2 1 0
Name RSa4F1 RSa4F3 RSa4F5 RSa4F7 RSa4F9 RSa4F11 RSa4F13 RSa4F15
Default 0 0 0 0 0 0 0 0
HW
Mode
X X X X X X X X
Bit 0/Sa4 Bit of Frame 15(RSa4F15).
Bit 1/Sa4 Bit of Frame 13(RSa4F13).
Bit 2/Sa4 Bit of Frame 11(RSa4F11).
Bit 3/Sa4 Bit of Frame 9(RSa4F9).
Bit 4/Sa4 Bit of Frame 7(RSa4F7).
Bit 5/Sa4 Bit of Frame 5(RSa4F5).
Bit 6/Sa4 Bit of Frame 3(RSa4F3).
Bit 7/Sa4 Bit of Frame 1(RSa4F1).
