DS26503 T1/E1/J1 BITS Element
114 of 123
19.2 Nonmultiplexed Bus
Table 19-2. AC Characteristics, Non-Mux Parallel Port
(V
DD
= 3.3V ±5%, T
A
= 0°C to +70°C for DS26503L; V
DD
= 3.3V ±5%, T
A
= -40°C to +85°C for
DS26503LN.)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Setup Time for A0 to A7, Valid to
CS Active
t1 0 ns
Setup Time for CS Active to
Either RD, WR, or DS Active
t2 0 ns
Delay Time from Either RD or
DS Active to Data Valid
t3 75 ns
Hold Time from Either RD, WR,
or DS Inactive to CS Inactive
t4 0 ns
Hold Time from CS Inactive to
Data Bus Tri-State
t5 5 20 ns
Wait Time from Either WR or DS
Activate to Latch Data
t6 75 ns
Data Setup Time to Either WR or
DS Inactive
t7 10 ns
Data Hold Time from Either WR
or DS Inactive
t8 10 ns
Address Hold from Either WR or
DS Inactive
t9 10 ns
