DS26503 T1/E1/J1 BITS Element
119 of 123
19.4 Receive Side AC Characteristics
Table 19-4. Receive Side AC Characteristics
(V
DD
= 3.3V ±5%, T
A
= 0°C to +70°C for DS26503L; V
DD
= 3.3V ±5%, T
A
= -40°C to +85°C for
DS26503LN.)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
488 ns 1
648 ns 2
RCLK Period t
CP
158.4 ns 5
t
CH
200 ns 3
RCLK Pulse Width
t
CL
200 ns 3
t
CH
150 ns 4
RCLK Pulse Width
t
CL
150 ns 4
RCLK to RSER Delay t
D1
20 ns
RCLK to RS Delay t
D2
50 ns
Note 1: E1 mode.
Note 2: T1 or J1 mode.
Note 3: Jitter attenuator enabled in the receive path.
Note 4: Jitter attenuator disabled or enabled in the transmit path.
Note 5: 6312kHz mode.
