DS26503 T1/E1/J1 BITS Element
65 of 123
Register Name:
RSiAF
Register Description: Receive Si Bits of the Align Frame
Register Address: 58h
Bit
# 7 6 5 4 3 2 1 0
Name SiF0 SiF2 SiF4 SiF6 SiF8 SiF10 SiF12 SiF14
Default 0 0 0 0 0 0 0 0
HW
Mode
X X X X X X X X
Bit 0/Si Bit of Frame 14(SiF14).
Bit 1/Si Bit of Frame 12(SiF12).
Bit 2/Si Bit of Frame 10(SiF10).
Bit 3/Si Bit of Frame 8(SiF8).
Bit 4/Si Bit of Frame 6(SiF6).
Bit 5/Si Bit of Frame 4(SiF4).
Bit 6/Si Bit of Frame 2(SiF2).
Bit 7/Si Bit of Frame 0(SiF0).
Register Name:
RSiNAF
Register Description: Receive Si Bits of the Non-Align Frame
Register Address: 59h
Bit
# 7 6 5 4 3 2 1 0
Name SiF1 SiF3 SiF5 SiF7 SiF9 SiF11 SiF13 SiF15
Default 0 0 0 0 0 0 0 0
HW
Mode
X X X X X X X X
Bit 0/Si Bit of Frame 15(SiF15).
Bit 1/Si Bit of Frame 13(SiF13).
Bit 2/Si Bit of Frame 11(SiF11).
Bit 3/Si Bit of Frame 9(SiF9).
Bit 4/Si Bit of Frame 7(SiF7).
Bit 5/Si Bit of Frame 5(SiF5).
Bit 6/Si Bit of Frame 3(SiF3).
Bit 7/Si Bit of Frame 1(SiF1).
