DS26503 T1/E1/J1 BITS Element
47 of 123
Table 9-1. E1 Sync/Resync Criteria
FRAME OR
MULTIFRAME
LEVEL
SYNC CRITERIA RESYNC CRITERIA ITU SPEC.
FAS FAS present in frame N and
N + 2, and FAS not present in
frame N + 1 Three consecutive incorrect FAS
received
Alternate: (E1RCR.2 = 1) The above
criteria is met or three consecutive
incorrect bit 2 of non-FAS received G.706
4.1.1
4.1.2
CRC4 Two valid MF alignment
words found within 8ms 915 or more CRC4 code words out of
1000 received in error G.706
4.2 and 4.3.2
CAS Valid MF alignment word
found and previous time slot
16 contains code other than
all zeros Two consecutive MF alignment
words received in error G.732 5.2
Register Name:
E1TCR
Register Description: E1 Transmit Control Register
Register Address: 1Eh
Bit
# 7 6 5 4 3 2 1 0
Name TFPT — — TSiS — — THDB3 —
Default 0 0 0 0 0 0 0 0
HW
Mode
0 0 0 0 0 0
HBE
PIN 55
0
Bit 0/Unused, must be set = 0 for proper operation.
Bit 1/Transmit HDB3 Enable (THDB3).
0 = HDB3 disabled
1 = HDB3 enabled
Bit 2/Unused, must be set = 0 for proper operation.
Bit 3/Unused, must be set = 0 for proper operation.
Bit 4/ Transmit International Bit Select (TSiS)
0 = sample Si bits at TSER pin
1 = source Si bits from TAF and TNAF registers (in this mode, E1TCR1.7 must be set to 0)
Bit 5/Unused, must be set = 0 for proper operation.
Bit 6/Unused, must be set = 0 for proper operation.
Bit 7/ Transmit Time Slot 0 Pass-Through (TFPT)
0 = FAS bits/Sa bits/remote alarm sourced internally from the TAF and TNAF registers
1 = FAS bits/Sa bits/remote alarm sourced from TSER
