DS26503 T1/E1/J1 BITS Element
67 of 123
Register Name: RSa5
Register Description: Receive Sa5 Bits
Register Address: 5Ch
Bit
# 7 6 5 4 3 2 1 0
Name RSa5F1 RSa5F3 RSa5F5 RSa5F7 RSa5F9 RSa5F11 RSa5F13 RSa5F15
Default 0 0 0 0 0 0 0 0
HW
Mode
X X X X X X X X
Bit 0/Sa5 Bit of Frame 15(RSa5F15).
Bit 1/Sa5 Bit of Frame 13(RSa5F13).
Bit 2/Sa5 Bit of Frame 11(RSa5F11).
Bit 3/Sa5 Bit of Frame 9(RSa5F9).
Bit 4/Sa5 Bit of Frame 7(RSa5F7).
Bit 5/Sa5 Bit of Frame 5(RSa5F5).
Bit 6/Sa5 Bit of Frame 3(RSa5F3).
Bit 7/Sa5 Bit of Frame 1(RSa5F1).
Register Name: RSa6
Register Description: Receive Sa6 Bits
Register Address: 5Dh
Bit
# 7 6 5 4 3 2 1 0
Name RSa6F1 RSa6F3 RSa6F5 RSa6F7 RSa6F9 RSa6F11 RSa6F13 RSa6F15
Default 0 0 0 0 0 0 0 0
HW
Mode
X X X X X X X X
Bit 0/Sa6 Bit of Frame 15(RSa6F15).
Bit 1/Sa6 Bit of Frame 13(RSa6F13).
Bit 2/Sa6 Bit of Frame 11(RSa6F11).
Bit 3/Sa6 Bit of Frame 9(RSa6F9).
Bit 4/Sa6 Bit of Frame 7(RSa6F7).
Bit 5/Sa6 Bit of Frame 5(RSa6F5).
Bit 6/Sa6 Bit of Frame 3(RSa6F3).
Bit 7/Sa6 Bit of Frame 1(RSa6F1).
