DS26503 T1/E1/J1 BITS Element
60 of 123
Register Name: IMR3
Register Description: Interrupt Mask Register 3
Register Address: 19h
Bit
# 7 6 5 4 3 2 1 0
Name RAIS-CI LOTC BOCC RFDLAD RFDLF TFDLE RMTCH RBOC
Default 0 0 0 0 0 0 0 0
HW
Mode
X X X X X X X X
Bit 0/Receive BOC Detector Change-of-State Event (RBOC).
0 = interrupt masked
1 = interrupt enabled
Bit 1/Receive FDL Match Event (RMTCH).
0 = interrupt masked
1 = interrupt enabled
Bit 2/TFDL Register Empty Event (TFDLE).
0 = interrupt masked
1 = interrupt enabled
Bit 3/RFDL Register Full Event (RFDLF).
0 = interrupt masked
1 = interrupt enabled
Bit 4/RFDL Abort Detect Event (RFDLAD).
0 = interrupt masked
1 = interrupt enabled
Bit 5/BOC Clear Event (BOCC).
0 = interrupt masked
1 = interrupt enabled
Bit 6/ Loss Of Transmit Clock Event (LOTC).
0 = interrupt masked
1 = interrupt enabled
Bit 7/Receive AIS-CI Event (RAIS-CI).
0 = interrupt masked
1 = interrupt enabled
