DS26503 T1/E1/J1 BITS Element
69 of 123
Register Name:
TSiAF
Register Description: Transmit Si Bits of the Align Frame
Register Address: 42h
Bit
# 7 6 5 4 3 2 1 0
Name TsiF0 TsiF2 TsiF4 TsiF6 TsiF8 TsiF10 TsiF12 TsiF14
Default
0 0 0 0 0 0 0 0
HW
Mode
0 0 0 0 0 0 0 0
Bit 0/Si Bit of Frame 14(TsiF14).
Bit 1/Si Bit of Frame 12(TsiF12).
Bit 2/Si Bit of Frame 10(TsiF10).
Bit 3/Si Bit of Frame 8(TsiF8).
Bit 4/Si Bit of Frame 6(TsiF6).
Bit 5/Si Bit of Frame 4(TsiF4).
Bit 6/Si Bit of Frame 2(TsiF2).
Bit 7/Si Bit of Frame 0(TsiF0).
Register Name:
TSiNAF
Register Description: Transmit Si Bits of the Non-Align Frame
Register Address: 43h
Bit
# 7 6 5 4 3 2 1 0
Name TsiF1 TsiF3 TsiF5 TsiF7 TsiF9 TsiF11 TsiF13 TSiF15
Default
0 0 0 0 0 0 0 0
HW
Mode
0 0 0 0 0 0 0 0
Bit 0/Si Bit of Frame 15(TSiF15).
Bit 1/Si Bit of Frame 13(TsiF13).
Bit 2/Si Bit of Frame 11(TsiF11).
Bit 3/Si Bit of Frame 9(TsiF9).
Bit 4/Si Bit of Frame 7(TsiF7).
Bit 5/Si Bit of Frame 5(TsiF5).
Bit 6/Si Bit of Frame 3(TsiF3).
Bit 7/Si Bit of Frame 1(TsiF1).
