DS26503 T1/E1/J1 BITS Element
104 of 123
Table 16-4. Boundary Scan Control Bits
CELL # NAME TYPE
CONTROL
CELL
0 AD1 Output3 1
1 AD1_7_CTRL Controlr
2 AD0 Output3 3
3 AD0_CTRL Controlr
4 WR_RW observe_only
5 RD_DS observe_only
6 CS observe_only
7 BIS1 observe_only
8 BIS0 observe_only
9 BTS observe_only
10 THZE observe_only
11 TMODE1 observe_only
12 TMODE2 observe_only
13 PLL_CLK observe_only
14 INT Output3 15
15 INT_CTRL Controlr
16 TSTRST observe_only
17 RLOS observe_only
18 TCSS1 observe_only
19 RLOF observe_only
20 RAIS observe_only
21 RSER observe_only
22 OUT_400HZ* observe_only
23 RS observe_only
24 RCLK observe_only
25 TS Output3 26
26 TS_CTRL Controlr
27 TSER observe_only
