DS26503 T1/E1/J1 BITS Element
22 of 123
4.7 Power
NAME TYPE FUNCTION
DVDD —
Digital Positive Supply. 3.3V ±5%. Should be tied to the RVDD and TVDD
pins.
RVDD —
Receive Analog Positive Supply. 3.3V ±5%. Should be tied to the DVDD and
TVDD pins.
TVDD —
Transmit Analog Positive Supply. 3.3V ±5%. Should be tied to the DVDD
and RVDD pins.
DVSS — Digital Signal Ground. 0.0V. Should be tied to the RVSS and TVSS pins.
RVSS —
Receive Analog Signal Ground. 0.0V. Should be tied to the DVSS and TVSS
pins.
TVSS —
Transmit Analog Signal Ground. 0.0V. Should be tied to the DVSS and
RVSS pins.
