DS26503 T1/E1/J1 BITS Element
33 of 123
ADDRESS TYPE REGISTER NAME
REGISTER
ABBREVIATION
43 R/W Transmit Si Non-Align Frame TSiNAF
44 R/W Transmit Remote Alarm Bits TRA
45 R/W Transmit Sa4 Bits TSa4
46 R/W Transmit Sa5 Bits TSa5
47 R/W Transmit Sa6 Bits TSa6
48 R/W Transmit Sa7 Bits TSa7
49 R/W Transmit Sa8 Bits TSa8
4A R/W Transmit Sa Bit Control Register TSACR
4B-4F — Reserved —
50 R Receive FDL Register RFDL
51 R/W Transmit FDL Register TFDL
52 R/W Receive Facility Data Link Match Register 1 RFDLM1
53 R/W Receive Facility Data Link Match Register 2 RFDLM2
54-55 — Reserved —
56 R Receive Align Frame Register RAF
57 R Receive Non-Align Frame Register RNAF
58 R Receive Si Align Frame RSiAF
59 R Receive Si Non-Align Frame RSiNAF
5A R Receive Remote Alarm Bits RRA
5B R Receive Sa4 Bits RSa4
5C R Receive Sa5 Bits RSa5
5D R Receive Sa6 Bits RSa6
5E R Receive Sa7 Bits RSa7
5F R Receive Sa8 Bits RSa8
60-EF — Reserved —
F0 R/W Test Register 1 TEST1*
F1 R/W Test Register 2 TEST2*
F2 R/W Test Register 3 TEST3*
F3 R/W Test Register 4 TEST4*
F4 R/W Test Register 5 TEST5*
F5 R/W Test Register 6 TEST6*
F6 R/W Test Register 7 TEST7*
F7 R/W Test Register 8 TEST8*
F8 R/W Test Register 9 TEST9*
F9 R/W Test Register 10 TEST10*
FA R/W Test Register 11 TEST11*
FB R/W Test Register 12 TEST12*
FC R/W Test Register 13 TEST13*
FD R/W Test Register 14 TEST14*
FE R/W Test Register 15 TEST15*
FF R/W Test Register 16 TEST16*
*TEST1 to TEST16 registers are used only by the factory.
