DS26503 T1/E1/J1 BITS Element
72 of 123
Register Name:
TSa7
Register Description: Transmit Sa7 Bits
Register Address: 48h
Bit
# 7 6 5 4 3 2 1 0
Name TSa7F1 TSa7F3 TSa7F5 TSa7F7 TSa7F9 TSa7F11 TSa7F13 TSa7F15
Default 0 0 0 0 0 0 0 0
HW
Mode
0 0 0 0 0 0 0 0
Bit 0/Sa7 Bit of Frame 15(TSa7F15).
Bit 1/Sa7 Bit of Frame 13(TSa7F13).
Bit 2/Sa7 Bit of Frame 11(TSa7F11).
Bit 3/Sa7 Bit of Frame 9(TSa7F9).
Bit 4/Sa7 Bit of Frame 7(TSa7F7).
Bit 5/Sa7 Bit of Frame 5(TSa7F5).
Bit 6/Sa7 Bit of Frame 3(TSa7F3).
Bit 7/Sa7 Bit of Frame 1(TSa4F1).
Register Name:
TSa8
Register Description: Transmit Sa8 Bits
Register Address: 49h
Bit
# 7 6 5 4 3 2 1 0
Name TSa8F1 TSa8F3 TSa8F5 TSa8F7 TSa8F9 TSa8F11 TSa8F13 TSa8F15
Default 0 0 0 0 0 0 0 0
HW
Mode
0 0 0 0 0 0 0 0
Bit 0/Sa8 Bit of Frame 15(TSa8F15).
Bit 1/Sa8 Bit of Frame 13(TSa8F13).
Bit 2/Sa8 Bit of Frame 11(TSa8F11).
Bit 3/Sa8 Bit of Frame 9(TSa8F9).
Bit 4/Sa8 Bit of Frame 7(TSa8F7).
Bit 5/Sa8 Bit of Frame 5(TSa8F5).
Bit 6/Sa8 Bit of Frame 3(TSa8F3).
Bit 7/Sa8 Bit of Frame 1(TSa8F1).
