DS26503 T1/E1/J1 BITS Element
68 of 123
Register Name:
RSa7
Register Description: Receive Sa7 Bits
Register Address: 5Eh
Bit
# 7 6 5 4 3 2 1 0
Name RSa7F1 RSa7F3 RSa7F5 RSa7F7 RSa7F9 RSa7F11 RSa7F13 RSa7F15
Default 0 0 0 0 0 0 0 0
HW
Mode
X X X X X X X X
Bit 0/Sa7 Bit of Frame 15(RSa7F15).
Bit 1/Sa7 Bit of Frame 13(RSa7F13).
Bit 2/Sa7 Bit of Frame 11(RSa7F11).
Bit 3/Sa7 Bit of Frame 9(RSa7F9).
Bit 4/Sa7 Bit of Frame 7(RSa7F7).
Bit 5/Sa7 Bit of Frame 5(RSa7F5).
Bit 6/Sa7 Bit of Frame 3(RSa7F3).
Bit 7/Sa7 Bit of Frame 1(RSa4F1).
Register Name:
RSa8
Register Description: Receive Sa8 Bits
Register Address: 5Fh
Bit
# 7 6 5 4 3 2 1 0
Name RSa8F1 RSa8F3 RSa8F5 RSa8F7 RSa8F9 RSa8F11 RSa8F13 RSa8F15
Default 0 0 0 0 0 0 0 0
HW
Mode
X X X X X X X X
Bit 0/Sa8 Bit of Frame 15(RSa8F15).
Bit 1/Sa8 Bit of Frame 13(RSa8F13).
Bit 2/Sa8 Bit of Frame 11(RSa8F11).
Bit 3/Sa8 Bit of Frame 9(RSa8F9).
Bit 4/Sa8 Bit of Frame 7(RSa8F7).
Bit 5/Sa8 Bit of Frame 5(RSa8F5).
Bit 6/Sa8 Bit of Frame 3(RSa8F3).
Bit 7/Sa8 Bit of Frame 1(RSa8F1).
