DS26503 T1/E1/J1 BITS Element
105 of 123
CELL # NAME TYPE
CONTROL
CELL
28 TPOSO observe_only
29 TNEGO observe_only
30 TCLKO observe_only
31 TCLK observe_only
32 ALE_A7 observe_only
33 A6 observe_only
34 A5 observe_only
35 A4 observe_only
36 A3 observe_only
37 A2 observe_only
38 A1 observe_only
39 A0 observe_only
40 AD7 Output3 1
41 AD6 Output3 1
42 AD5 Output3 1
43 AD4 Output3 1
44 AD3 Output3 1
45 AD2 Output3 1
* This pin is not bonded out on the DS26503 package, however, it must be
accounted for in the chain.
