DS26503 T1/E1/J1 BITS Element
70 of 123
Register Name:
TRA
Register Description: Transmit Remote Alarm
Register Address: 44h
Bit
# 7 6 5 4 3 2 1 0
Name TRAF1 TRAF3 TRAF5 TRAF7 TRAF9 TRAF11 TRAF13 TRAF15
Default
0 0 0 0 0 0 0 0
HW
Mode
0 0 0 0 0 0 0 0
Bit 0/Remote Alarm Bit of Frame 15(TRAF15).
Bit 1/Remote Alarm Bit of Frame 13(TRAF13).
Bit 2/Remote Alarm Bit of Frame 11(TRAF11).
Bit 3/Remote Alarm Bit of Frame 9(TRAF9).
Bit 4/Remote Alarm Bit of Frame 7(TRAF7).
Bit 5/Remote Alarm Bit of Frame 5(TRAF5).
Bit 6/Remote Alarm Bit of Frame 3(TRAF3).
Bit 7/Remote Alarm Bit of Frame 1(TRAF1).
Register Name:
TSa4
Register Description: Transmit Sa4 Bits
Register Address: 45h
Bit
# 7 6 5 4 3 2 1 0
Name TSa4F1 TSa4F3 TSa4F5 TSa4F7 TSa4F9 TSa4F11 TSa4F13 TSa4F15
Default 0 0 0 0 0 0 0 0
HW
Mode
0 0 0 0 0 0 0 0
Bit 0/Sa4 Bit of Frame 15(TSa4F15).
Bit 1/Sa4 Bit of Frame 13(TSa4F13).
Bit 2/Sa4 Bit of Frame 11(TSa4F11).
Bit 3/Sa4 Bit of Frame 9(TSa4F9).
Bit 4/Sa4 Bit of Frame 7(TSa4F7).
Bit 5/Sa4 Bit of Frame 5(TSa4F5).
Bit 6/Sa4 Bit of Frame 3(TSa4F3).
Bit 7/Sa4 Bit of Frame 1(TSa4F1).
