DS26503 T1/E1/J1 BITS Element
58 of 123
Register Name:
RFDL (RFDL register bit usage when BOCC.4 = 1)
Register Description: Receive FDL Register
Register Address: 50h
Bit
# 7 6 5 4 3 2 1 0
Name — — RBOC5 RBOC4 RBOC3 RBOC2 RBOC1 RBOC0
Default 0 0 0 0 0 0 0 0
HW
Mode
0 0 0 0 0 0 0 0
Bit 0/BOC Bit 0 (RBOC0).
Bit 1/BOC Bit 1 (RBOC1).
Bit 2/BOC Bit 2 (RBOC2).
Bit 3/BOC Bit 3 (RBOC3).
Bit 4/BOC Bit 4 (RBOC4).
Bit 5/BOC Bit 5 (RBOC5).
Bit 6/This bit position is unused when BOCC.4 = 1.
Bit 7/This bit position is unused when BOCC.4 = 1.
Register Name:
RFDLM1, RFDLM2
Register Description: Receive FDL Match Register 1
Receive FDL Match Register 2
Register Address: 52h, 53h
Bit # 7 6 5 4 3 2 1 0
Name RFDLM7 RFDLM6 RFDLM5 RFDLM4 RFDLM3 RFDLM2 RFDLM1 RFDLM0
Default 0 0 0 0 0 0 0 0
HW
Mode
0 0 0 0 0 0 0 0
Bit 0/Receive FDL Match Bit 0 (RFDLM0). LSB of the FDL Match Code.
Bit 1/Receive FDL Match Bit 1 (RFDLM1).
Bit 2/Receive FDL Match Bit 2 (RFDLM2).
Bit 3/Receive FDL Match Bit 3 (RFDLM3).
Bit 4/Receive FDL Match Bit 4 (RFDLM4).
Bit 5/Receive FDL Match Bit 5 (RFDLM5).
Bit 6/Receive FDL Match Bit 6 (RFDLM6).
Bit 7/Receive FDL Match Bit 7 (RFDLM7). MSB of the FDL Match Code.
