DS26503 T1/E1/J1 BITS Element
75 of 123
Register Name:
RNAF
Register Description: Receive Non-Align Frame Register
Register Address: 57h
Bit
# 7 6 5 4 3 2 1 0
Name Si 1 A Sa4 Sa5 Sa6 Sa7 Sa8
Default
0 0 0 0 0 0 0 0
HW
Mode
X X X X X X X X
Bit 0/Additional Bit 8 (Sa8).
Bit 1/Additional Bit 7 (Sa7).
Bit 2/Additional Bit 6 (Sa6).
Bit 3/Additional Bit 5 (Sa5).
Bit 4/Additional Bit 4 (Sa4).
Bit 5 / Remote Alarm (A).
Bit 6/Frame Nonalignment Signal Bit (1). In normal operation this bit will be = 1.
Bit 7/International Bit (Si).
Register Name:
TAF
Register Description: Transmit Align Frame Register
Register Address: 40h
Bit
# 7 6 5 4 3 2 1 0
Name Si 0 0 1 1 0 1 1
Default
0 0 0 1 1 0 1 1
HW
Mode
0 0 0 1 1 0 1 1
Bit 0/Frame Alignment Signal Bit (1).
Bit 1/Frame Alignment Signal Bit (1).
Bit 2/Frame Alignment Signal Bit (0).
Bit 3/Frame Alignment Signal Bit (1).
Bit 4/Frame Alignment Signal Bit (1).
Bit 5/Frame Alignment Signal Bit (0).
Bit 6/Frame Alignment Signal Bit (0).
Bit 7/International Bit (Si).
