DS26503 T1/E1/J1 BITS Element
54 of 123
Register Name:
IOCR2
Register Description: I/O Configuration Register 2
Register Address: 02h
Bit
# 7 6 5 4 3 2 1 0
Name
RCLKINV TCLKINV RSINV TSINV — — — —
Default 0 0 0 0 0 0 0 0
HW
Mode
0 0 0 0 0 0 0 0
Bit 0/Unused, must be set = 0 for proper operation.
Bit 1/Unused, must be set = 0 for proper operation.
Bit 2/Unused, must be set = 0 for proper operation.
Bit 3/Unused, must be set = 0 for proper operation.
Bit 4/TS Invert (TSINV).
0 = no inversion
1 = invert
Bit 5/RS Invert (RSINV).
0 = no inversion
1 = invert
Bit 6/TCLK Invert (TCLKINV).
0 = no inversion
1 = invert
Bit 7/RCLK Invert (RCLKINV).
0 = no inversion
1 = invert
