9. 30"-36" Head Platform Left Hand Drive
PNEG-1849 30"-36" Bucket Elevator Platform and Ladder “X” Series
63
Figure 9B 30" Left Side Drive Channel Position
Figure 9C 30" Left Drive - Cross Deck Support Channels to Lower Head Brackets
X7
X5
X4
X3
X2
X1
X7
X5
X4
X3
X2
X1
Six (6) bolt holes at this end.
Eight (8) bolt holes at this end.
Lower head here
Discharge end
Up-leg end
X6
X6
Non-drive side
(Hatch located on this side.)
Drive side
Note orientation of channel
Holes etched on channel
Holes etched on channel
30" Left
