Figure 8d and, X5 y6 – Grain Systems Bucket Elevtors, Conveyors, Series II Sweeps PNEG-1849 User Manual
Page 49
8. 30"-36" Head Platform Right Hand Drive
PNEG-1849 30"-36" Bucket Elevator Platform and Ladder “X” Series
49
Figure 8D 36" Right Side Drive Channel Position
Figure 8E
Lower head here
Non-drive side
(Hatch located on this side.)
Drive side
Y1
Note orientation of channel
Holes etched on channel
Y2
Y3
Y4
Y5
Y7
X1
X2
X3
X4
X6
X7
Holes etched on channel
Six (6) bolt holes at this end.
Eight (8) bolt holes at this end.
Discharge end
Up-leg end
X5
Y6
36" Right
