13. 6 x 6 Distributor Platforms
102 PNEG-1849 30"-36" Bucket Elevator Platform and Ladder “X” Series
Cross Braces for Knee Braces
Attach knee brace diagonals to bottom side of the knee braces, this will add extra stability to the distributor
platform.
(See Figure 13D below and Figure 13E on Page 103.)
Figure 13D
See detail J
on Page 103
See detail I
on Page 103
