Properly, Figure 8b and, Y5 y6 – Grain Systems Bucket Elevtors, Conveyors, Series II Sweeps PNEG-1849 User Manual
Page 47
8. 30"-36" Head Platform Right Hand Drive
PNEG-1849 30"-36" Bucket Elevator Platform and Ladder “X” Series
47
Figure 8B 30" Right Side Drive Channel Position
Figure 8C 30" Right Drive - Cross Deck Support Channels to Lower Head Brackets
Lower head here
Non-drive side
(Hatch located on this side.)
Drive Side
Y1
Note orientation of channel
Holes etched on channel
Y2
Y3
Y4
Y6
Y7
Y1
Y2
Y3
Y4
Y5
Y7
Holes etched on channel
Six (6) bolt holes at this end.
Eight (8) bolt holes at this end.
Dischar
ge end
Up-leg end
Y5
Y6
30" Right
