Using the windows nt 4.0 postscript driver – Tektronix 560 User Manual
Page 70
4
Printing Basics
4-6
Phaser 560 Color Laser Printer
Using the Windows NT 4.0 PostScript driver
When using Microsoft Windows NT 4.0, make sure that you have first installed and set up a driver for a
Phaser 560 printer (refer to page 3-4). Then, select printer features (such as TekColor color corrections)
from the Windows NT driver.
Selecting printer options from the Control Panel
Note
Document properties set from an application always override document defaults set in the printer’s
Properties sheets. However, if an application does not set a document property (such as page
orientation or paper size), the printer defaults to the document properties set in the printer’s Document
Properties sheets.
To view a printer’s
Default Document Properties
:
1.
Open the
Printers
folder.
2.
With the right mouse button, click on the printer’s icon.
3.
With the left mouse button, click on
Document Defaults.
4.
Click the
Advanced
tab to change any printer features, including TekColor.
5.
Click the
Page Setup
tab to see other features.
Note
Select
Installed
for the optional Lower Tray Assembly if your printer has this accessory. You must
make this selection for the optional media trays to be available under
Document Defaults
.
Print command options in an application
Note
Changes to any of these settings override the
Default Printer Properties
settings in the
Printers
folder.
1.
Select
from the
File
menu; the
dialog box appears. You can select a different printer and
other settings in this dialog box.
2.
Click on the
Properties
button; the
Printer Document Properties
sheet appears.
3.
Click the
Advanced
tab to change any printer features, including TekColor. This tab displays the same
information as the
Document Defaults Properties Advanced
tab.
4.
Click the
Page Setup
tab to see other features. This tab displays the same information as the
Documents Defaults Properties Page Setup
tab.
