Troubleshooting 7
User Manual 7-11
On the Consumables Page,
each color “bleeds” into the
color band below it (the most
visible is magenta in the
yellow band). The Imaging Unit’s internal waste
toner box is full. Replace the Imaging Unit.
A single white spot appears
in approximately the same
vertical place on the page. The Imaging Unit is damaged. Replace the Imaging Unit.
A single, wide, light horizontal
band appears in one place on
the page (near the top)
or all
colors are faded.
The Imaging Unit was exposed too
long to light. Wait overnight and print the Consumables
Page. If print quality hasn’t changed,
replace the Imaging Unit.
Troubleshooting and print quality quick reference (cont'd.)
Symptom Possible Causes Solution
