Troubleshooting
7
User Manual
7-41
Jam at B
Solution 1
Solution 2
1.
Open the
lower
left side door.
2.
Remove the complete piece of jammed media.
1.
Remove the selected media tray (
Middle
or
Lower
media tray).
2.
Remove the complete piece of jammed media
from inside the printer.
9698-57
9698-89
1
2
Legal
Paper
A/Letter
Paper
9698-32
A/Letter
Paper
1
2
A/Letter
Paper
A/Letter
Paper
9698-32
A/Letter
Paper
