6 Caring for Your Printer
6-8 Phaser 560 Color Laser Printer
Fuser Roll
Note A Fuser Roll is always included with each replacement Fuser.
Front panel
messages Fuser Roll:replace Replace the Fuser Roll soon. After the message
appears, the Fuser Roll may still yield about
500 pages.
Stopped:
Fuser Roll:replace Replace the Fuser Roll now ; the printer stops until you
replace the Fuser Roll.
Diagnosing print
quality ■ A piece of the printed image is
missing and reappears out of
place.
■ A piece of the printed image
appears faded.
■ If media frequently wraps around
the Fuser.
■ Print the Consumables Page from the front panel.
■ Check the % Remaining gauge.
■ Print the Configuration Page from the front panel or
access the front panel System Counts menu.
■ Check the Fuser Roll Count ; compare the
number to the component’s average life (refer to
page 6-3).
Replacing the
Fuser Roll 1. Open the printer’s front door and remove the Fuser.
2. Unlock the Fuser Roll by pressing outward on its tabs; remove the Fuser Roll
and dispose of it as normal office waste.
3. Unpack the new Fuser Roll. Be careful not to touch the oiled cloth.
4. Place the new roll into the Fuser; press down firmly on the roll with both hands
to lock it into place.
5. Slide the Fuser into the printer and tighten the thumbscrew.
Close the printer’s front door.
