Caring for Your Printer
6-2
Phaser 560 Color Laser Printer
User-replaceable components
This printer is designed modularly so that it is easy to maintain: several of
the components are replaceable. Cleaning is only necessary if you
experience frequent media jams (see “Cleaning the paper-pick and
paper-feed rollers” on page 6-12).
These are the replaceable components for the printer:
1.
Transfer Kit (transfer roller/waste bin)
2.
Imaging Kit (Imaging Unit and filter)
3.
Fuser Roll
4.
Fuser
5.
Toner Cartridges
6.
Main Charge Grid
9698-22
1
2
3
4
6
5
