Preparing the imaging unit
Before operating the printer, you must perform these steps to prepare the
imaging unit for printing:
1.
Open the printer’s front door.
2.
Turn the upper lever 90˚ clockwise to align the lever’s triangle
with the triangle on the surface of the imaging unit.
3.
Close the printer’s front door.
