Getting Set Up 2
User Manual 2-13
Types and sizes of media trays
The printer uses five unique media trays, as well as the multi-purpose feeder
for any media type:
Note For the best print quality, make sure that you load the correct
media; each tray is designed and labeled for
only Paper or
Transparency. Although the printer will still print if you load the
wrong media type in a tray, the print quality will suffer.
If you have the Lower Tray Assembly installed and you wish to use
the automatic tray-switching feature (for example, for a large print
job), make sure that all trays in the printer at any one time are loaded
with the
same media type and size.
Multi-Purpose Feeder
For instructions on loading media into and printing from the
Multi-Purpose Feeder, refer to “Using the Multi-Purpose Feeder”
on page 4-40.
Tray Media Type Size
A/Letter Paper standard
8.5 x 11 in.
A/Letter Transparency optional
A4 Paper optional
210 x 297 mm
A4 Transparency optional
Legal Paper optional 8.5 x 14 in.
216 x 356 mm
Multi-Purpose
Feeder Paper standard 3.5 x 10 in. to 8.5 x 14 in.
Transparency 8.5 x 11 in.
210 x 297 mm
Specialty media 3.5 x 10 in. to 8.5 x 14 in.
89 x 254 mm to 216 x 356 mm
