Installing Printer Software 3
User Manual 3-11
AdobePS 3 Driver for Windows 3.1: Setup instructions
If you selected the AdobePS 3 Driver for Windows 3. 1 in the Custom Installation , continue with the following
instructions:
1. In the Adobe installer, click Read or Skip in the README.WRI dialog box to start the installation.
2. Click Continue in the PostScript Printer Driver Setup dialog box. Files are copied to your computer.
3. Click the Restart Windows button in the dialog box that appears.
4. After Windows restarts, the Install PostScript Printer from PPD dialog box opens. Select your printer in the list
and click Install :
■ Tektronix Phaser 560 Extended
(Extended Features option)
■ Tektronix Phaser 560
(standard printer configuration)
5. Click OK in the next dialog box.
6. Click Close in the Install PostScript Printer from PPD dialog box.
7. Click OK in the information dialog box.
8. In the Control Panel , double-click Printers .
9. In the Printers dialog box, select the printer you just installed, and click Connect .
10. In the Connect dialog box, select the port the printer is connected to, and click OK .
