10 Regulatory Information and Specifications
10-8 Phaser 560 Color Laser Printer
Dimensions with Lower Tray Assembly
Height: 678 mm (26.7 in.)
Depth: 492 mm (19.4 in.)
Width: 507 mm (20* in.)
*782 mm (30.8 in.) with the output tray
Weight of standard unit with all consumables (without Lower Tray Assembly)
47.5 kg (104.6 lbs.)
Weight of Lower Tray Assembly
14.3 kg (31.6 lbs.)
Printing speed
The speeds and rates listed in the following table represent the time it takes
the printer to produce a print (
1st print ) and the rate at which the printer
produces multiple prints ( Continuous throughput rate ). In both cases these are
physical mechanism times, independent of image processing time. Actual
time to first print depends on image complexity and size, resolution, and
memory configuration.
Safety and emissions standards
FCC Part 15, Subpart J “Class B” verified
Vfg 243 Class B
CISPR 22 Class B, verified
UL 1950, listed.
CSA 220, certified.
EN60950/IEC 950, TUV licensed
EN55022
Print mode
Color Monochrome
1st
print Continuous
throughput rate
(ppm)* 1st
print Continuous
throughput rate
(ppm)*
Fast Monochrome 26 sec.** 14 ** 26 14
Fast Color 40 sec. 4.7 55 sec. 4.7
Standard /
Presentation 43 sec. 3.5 26 sec. 14
Premium 1 min. 20 sec. 1.8 50 sec. 7
Transparency 1 min. 20 sec. 1.5 60 sec. 7
* Pages per minute.
** Output from Fast Monochrome will always be black-and-white.
