Number Description Number Description
1 XSCF-LAN#0 address
(XSCFU#0 side) 7 ISN address
(XSCFU#0 side)
2 XSCF-LAN#0 address
(XSCFU#1 side) 8 ISN address
(XSCFU#1 side)
3 Takeover address
between XSCF-LAN#0s 9 DSCP link address
(XSCF side)
4 XSCF-LAN#1 address
(XSCFU#0 side) 10 or
later DSCP link addresses
(Domains side)
5 XSCF-LAN#1 address
(XSCFU#1 side)
6 Takeover address
between XSCF-LAN#1s
2-20 SPARC Enterprise Mx000 Servers XSCF User’s Guide • April 2008
XSCF network configuration procedure and the reference
The procedure to set up the XSCF network is as follows. Each step offers the detailed
procedure reference.
Note – You must set XSCF-LAN, ISN, and DSCP in different subnet addresses. The
ISN address has been set up with the default value (see TABLE 2-2 ).
1. Specify the IP address of Ethernet (XSCF-LAN).
You can use two XSCF-LAN ports in accordance with the network configuration. In
the midrange system, specify the either or both of the following IP addresses:
■ XSCF-LAN#0 of XSCFU#0 (See "1" in FIGURE 2-1 )
■ XSCF-LAN#1 of XSCFU#0 (See "4" in FIGURE 2-1 )
In the high-end system, subsequently to the XSCFU#0 side, specify the IP address of
XSCF-LAN of the XSCFU#1 side (see "2" and "5" in
FIGURE 2-1 ). (See shownetwork
(8), setnetwork (8).)
Use the same subnet address to specify the LAN ports which share the same number
in each XSCF unit so that you can connect to both of the XSCF in case the XSCF
failover generated.
