TABLE 3-1 Types of Terminals Connected With XSCF
Port Terminal Type Port Number, Cable
XSCF-LAN port
(2 ports per XSCF
Unit)
[10/100 Mbps] • XSCF Shell terminal
• You can use the XSCF Shell with SSH or telnet connection.
• Either of the two XSCF-LAN ports can be used concurrently by
more than one user. (Note 1)
• Switching to the domain console is enabled by the console (8)
command.
After login, if the XSCF Shell is not used for a certain period, the
user is forcibly logged out.
To return to the shell window from the domain console, press the
"#." (sharp and period) keys (default) while holding down the
key. For details on changing these default keys, see the
description on the console (8) command.
SSH: 22
telnet: 23
A LAN cable is
required.
• Domain console (RW console)
• OS console enabled for input and output. The RW console is
enabled by specifying a write-enabled console in the console
(8) command from the shell terminal.
• In one domain, only one user (one connection) at a time can use
the RW console.
The domain console is not forcibly logged out.
(Note 2)
• Domain console (RO console)
• OS console used for display only. The RO console is enabled by
specifying a reference-only console in the console (8)
command from the shell terminal.
The domain console is not forcibly logged out.
• The XSCF Web can be used by specifying a URL in a browser. https: 443
A LAN cable is
required.
Serial port
(One per XSCF Unit) • XSCF Shell terminal
• The XSCF Shell can be used immediately following connection
to a serial port.
• As with that of the XSCF-LAN port, a screen transition to the
domain console is possible.
After login, if the XSCF Shell is not used for a certain period, the
user is forcibly logged out.
A RS-232C serial
crosscable is
required.
If only a LAN cable
is available, a 9-pin
conversion cable is
required on the PC
side.
• Domain console (RW console)
• This console is similar to that of the XSCF-LAN port.
• Domain console (RO console)
• This console is similar to that of the XSCF-LAN port.
