1-18 SPARC Enterprise Mx000 Servers XSCF User’s Guide • April 2008
1.3.3 About the CD-RW/DVD-RW Drive Unit and Tape
Drive Unit
A basic cabinet and an expansion cabinet contain one CD-RW/DVD-RW drive unit
and tape drive unit (hereafter collectively called DVD drive/tape drive unit)
respectively, and they are assigned to a single operating domain of each cabinet. In
the midrange system, the domain that uses a minimum XSB number of number 0 of
the MotherBoard Unit (MBU#0) can use the DVD/tape drive unit.
In the high-end systems, the DVD drive / tape drive unit can be used by assigning
it to a specific card port on the I/O unit. To assign a different port, specify the unit
by using the XSCF Shell. For details on this DVD drive / tape drive unit setting, see
Chapter 2 .
1.4 XSCF User Interfaces
This section describes the XSCF user interfaces.
1. XSCF Shell (Ethernet Connection):
A set of shell commands you can use from a PC or a terminal connected to the XSCF
over an XSCF-LAN Ethernet connection using SSH or telnet.
In the XSCF Shell (Ethernet connection) terminal, the console for each running
domain can also be used.
2. XSCF Shell (Serial Connection):
A set of shell commands you can use from a PC or terminal directly connected to the
XSCF by a serial cable.
In the XSCF Shell (Serial connection) terminal, the console for each running domain
can also be used.
3. XSCF Web:
A set of browser user interface (BUI) operations you can use from a web browser
connected to the XSCF over the XSCF-LAN Ethernet.
4. XSCF SNMP Agent functions:
SNMP manager commands used to monitor the operation of the server's network
functions.
5. XSCF mail functions:
