2-100 SPARC Enterprise Mx000 Servers XSCF User’s Guide • April 2008
Note – For the procedure for installing, removing, or replacing a system board in
the server, see the Service Manual for your server. Also, for details on using the DR
function, see the Dynamic Reconfiguration User’s Guide.
Note – For an overview of configuring domains, including an extensive example,
refer to the Administration Guide.
TABLE 2-24 lists setting items and the corresponding shell commands.
TABLE 2-24 Domain Configuration
Item Description Shell command Remarks
Display XSB
status Displays the XSB status for the specified
domain or all domains.
For XSB status information, see
TABLE 2-23 .
showboards
Display
domain status Displays one of the following items for the
current domain status:
For details of domain status, see
TABLE 2-22 .
showdomainstatus
showdcl
Display
resource use
state Displays the use status of devices and
resources on an XSB. showdevices
Display DCL
information Displays the DCL information for a system
board in the specified domain. showdcl
DCL (domain
configuration
information) Sets DCL information.
Specify configuration for LSB of specified
domain.
For details of configuration information, see
TABLE 2-22 .
setdcl "Omit-memory", "Omit-
I/O", and "Floating
board" are false by
default.
Add to domain Adds or assigns an XSB to a domain,
according to DCL information.
Specify the following:
• Domain ID and number of the added XSB
• assign
Specify one of the following integration
states when the domain is running (the DR
function):
• configure (OS connection request)
• assign (assign (reserve))
• reserve (assign (reserve))
addboard If the XSB is placed in
the assign (assign
(reserve)) state, a reboot
of the assigned domain
or the addboard (8)
command with
"configure" specified
would configure the
board into a running
Solaris OS domain (the
DR function).
