Lenovo ThinkServer RD650 User Manual
Page 49
Lenovo ThinkServer 9286 RAID Adapter
The following illustration shows the connectors on the Lenovo ThinkServer 9286 RAID Adapter.
Figure 18. Lenovo ThinkServer 9286 RAID Adapter
1
ThinkServer RAID Super Capacitor Module connector
Used to connect to the ThinkServer RAID Super Capacitor Module. See “Server components” on page 28.
2 3
SAS connector
Used to connect external storage devices.
35
