6. Open the small handle 1 first by gently pressing down the handle a little bit and then pushing the handle
inward to release it from the secured position. Then, open the other small handle 2 in the same way.
Note: There are two marks on the microprocessor retainer. Open the small handle marked with
first and then open the other small handle marked with . Always follow the correct sequence when
you open the small handles.
Figure 98. Opening the handles of the microprocessor retainer
7. Gently press the microprocessor retainer as shown to open it. Ensure that the small handles and the
microprocessor retainer are in the fully open position.
Note: Do not drop anything onto the microprocessor socket while it is exposed. The socket pins must
be kept as clean as possible.
Figure 99. Opening the microprocessor retainer
8. Touch the static-protective package that contains the new microprocessor to any unpainted surface on
the outside of the server. Then, remove the new microprocessor from the package.
Chapter 6 . Replacing hardware 125
