5. Install a new PCIe card to replace the old one or install a PCIe card slot bracket to cover the place. See
“Installing a PCIe card on the system board” on page 95.
6. If you are instructed to return the old PCIe card, follow all packaging instructions and use any packaging
materials that are supplied to you for shipping.
What to do next:
• To work with another piece of hardware, go to the appropriate section.
• To complete the removal procedure, go to “Completing the parts replacement” on page 183.
Replacing the AnyRAID adapter or the pass-through board
Attention: Do not open your server or attempt any repair before reading and understanding “Safety information”
on page iii and “Guidelines” on page 67.
Before you begin, print all the related instructions or ensure that you can view the PDF version on another
computer for reference.
Notes:
• Use any documentation that comes with the new AnyRAID adapter or the pass-through board and follow
those instructions in addition to the instructions in this topic.
• Depending on the model, your AnyRAID adapter or the pass-through board might look different from
the illustrations in this topic.
To replace the AnyRAID adapter or the pass-through board, do the following:
Attention: Replacing the AnyRAID adapter or the pass-through board might impact your RAID configurations.
Back up your data before you begin to avoid any data loss due to a RAID configuration change.
1. Remove all media from the drives and turn off all attached devices and the server. Then, disconnect all
power cords from electrical outlets and disconnect all cables that are connected to the server.
2. Prepare your server. See “Removing or extending the server from the rack cabinet” on page 69.
3. Remove the server cover. See “Removing the server cover” on page 69.
4. Locate the AnyRAID adapter or the pass-through board. See “Server components” on page 28.
.
101
