Lenovo ThinkServer RD650 - Manual (Page 143)

6. Locate the microprocessor socket. Open the small handle 1 first by gently pressing down the handle a
little bit and then pushing the handle inward to release it from the secured position. Then, open the
other small handle
2 in the same way.
Note: There are two marks on the microprocessor retainer. Open the small handle marked with
first and then open the other small handle marked with . Always follow the correct sequence when
you open the small handles.
Figure 104. Opening the handles of the microprocessor retainer
7. Gently press the microprocessor retainer as shown to open it. Ensure that the small handles and the
microprocessor retainer are in the fully open position.
Figure 105. Opening the microprocessor retainer
Chapter 6 . Replacing hardware 129
