Lenovo ThinkServer RD650 User Manual
Page 183
8. Slide the tape drive cage with the tape drive into the chassis from the front of the server.
Figure 165. Installing the tape drive cage with the tape drive into the chassis
9. Install five screws to secure the tape drive cage to the chassis.
Figure 166. Installing five screws to secure the tape drive cage to the chassis
.
169
