1 Power supply 2 (available on some models)
2 Power supply 1
The hot-swap redundant power supplies help you avoid significant interruption to the operation of the
system when a power supply fails. You can purchase a power supply option from Lenovo and install the
power supply to provide power redundancy without turning off the server.
On each power supply, there are three status LEDs near the power cord connector. For information about
the status LEDs, see “Power supply status LEDs” on page 51.
3 4 7 PCIe slots on the system board
Slot Physical link width Negotiable link width Supported card length and height
3 PCIe slot 8 x16 x8, x4, x2, x1 Low-profile card
4 PCIe slot 7 x16 x8, x4, x2, x1 Low-profile card
7 PCIe slot 4 x16 x8, x4, x2, x1 Low-profile card
5 6 PCIe slots on riser card assembly 2
Slot Physical link width Negotiable link width Supported card length and height
5 PCIe slot 5 x16 x8, x4, x2, x1 Half-length, full-height card
6 PCIe slot 6 x16 x8, x4, x2, x1 Half-length, full-height card
8 9 10 PCIe slots on riser card assembly 1
Slot Physical link width Negotiable link width Supported card length and height
8 PCIe slot 1 x16 x8, x4, x2, x1 Half-length, full-height card
9 PCIe slot 2 x16 x8, x4, x2, x1 Half-length, full-height card
10 PCIe slot 3 x16 x8, x4, x2, x1 Half-length, full-height card
26 ThinkServer RD650 User Guide and Hardware Maintenance Manual
