10.4 Absolute Position Detection for Infinite Length Axes
10.4.3 Detailed Descriptions on Parameter Settings for Simple Absolute Infinite Length Axes
10-19
10
Absolute Position Detection
( 3 ) Maximum Number of Absolute Encoder Turns Rotation/Multiturn Limit Setting
These parameters determine the maximum value of the number of encoder turns managed by the SERVOPACK and
Machine Controller.
For an infinite length axis, set the parameters as shown in the table below.
* If the Machine Controller fixed parameter 38 is set to 65535 when using a Σ-II, Σ-III, or Σ-V series SERVOPACK for
an infinite axis, a fixed parameter setting error will occur.
Applicable
SERVOPAC K
Fixed Parameter 38
(Maximum Number of Absolute Encoder
Turns Rotation)
SERVOPACK
Parameter Pn205
(Multiturn Limit Setting)
Σ-II/Σ-III/Σ-V Series Set the same value as Pn205 * 65534 max. *
Σ-I Series 99999 –
If the above settings are not used, correct motion control will not be performed resulting in position error. Set
the parameters correctly.
