Comparison: Differences in programming station
Function TNC 640 iTNC 530
Demo version Programs with more than 100
NC blocks cannot be selected, an
error message is issued Programs can be selected, max.
100 NC blocks are displayed,
further blocks are truncated in the
display
Demo version If nesting with PGM CALL results
in more than 100 NC blocks, there
is no test graphic display; an error
message is not issued Nested programs can be
simulated.
Copying NC programs Copying to and from the directory
TNC:\ is possible with Windows
Explorer TNCremo or file manager of
programming station must be
used for copying
Shifting the horizontal soft-key
row Clicking the soft-key bar shifts the
soft-key row to the right, or to the
left Clicking any soft-key bar activates
the respective soft-key row
